Perfect Bucket Elevators

Get a Price/Quote

MOQ : 1 Piece

Perfect Bucket Elevators Specification

Operating Temperature
-10C to 60C

Frame Type
Mild Steel/Stainless Steel

Power Rating
Standard / Customized

Frequency
50-60 Hz

Accuracy
High

Voltage
220V/380V, 3 Phase

Machine Type
Elevator

Drive
Electric Motor

Cooling System
Natural Air Cooling

Connectivity Options
Manual/Electrical

Lubricating System
Centralized or Manual

Model No
Customized

Features
Corrosion Resistant, High Efficiency, Minimal Spillage

Noise Level
Low

Production Capacity
As required

Motor Power
3 to 7.5 HP

Product Type
Bucket Elevator

Technology
Mechanical Handling

Power Source
Electric

Operating Type
Automatic

Power
3-7.5 kW (depending on model)

Pressure
Atmospheric

Surface Treatment
Powder Coated / Painted

Dimension (L*W*H)
Custom/As per design

Weight (kg)
Variable (Up to 1000 kg depending on capacity)

Color
Blue & White

Usage & Applications
Ready Mix, Feed, Cement, Grain Transfer

Safety Features
Overload Protection, Emergency Stop, Safety Guards

Maintenance Requirement
Low

Enclosure
Dustproof design

Intake Hopper
Integrated (with vibration option)

Start/Stop Mechanism
Remote/Electrical Start

Conveying Medium
Dry Bulk Material

Vibration Level
Minimal

Discharge Height
Customizable up to 30m

Chain Type
Heavy Duty (optional for higher loads)

Bucket Material
High-strength Polymer/Steel options

Service Access
Inspection panels provided

Installation
Indoor / Outdoor

Belt Type
Rubber/Canvas

Perfect Bucket Elevators Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
10 Pieces Per Month

Delivery Time
7-10 Days

About Perfect Bucket Elevators

Perfects Bucket Elevators are suitable for all kinds of grains. Elevator can be supplied at any height as per the need of the customer, between 10" and 50'.

Salient Features

Heavy in construction.
Compact design.
Maintainance free
Laser cutting
Powder-coated finish.
PPCP AA Buckets
White synthetic belts.
Chain and sprocket coupling.
Nylock nuts and HT bolt.
Aspiration mouth for dust.
Long life.

Specification

SI No.	Description	5"	6"	8"	10"	12"	14"
1	Model No.	SEN A	SEN 1	SEN 2	SEN 3	SEN 4	SEN 5
2	Capacity in TPH Paddy	4	6	9	16	19	22
3	Capacity in TPH - Rice	5	8	12	21	25	30
4	Pulley Dia x W in inches	12 x 5	12 x 6	12 x 8	16 x 10	16 x 12	18 x 14
5	Box Inner Size in mm	186 x 178	205 x 200	280 x 225	306 x 242	400 x 270	475 x 364
6	Power in HP (1440 RPM)	1	1	2	3	5	5
7	Elevator Speed in RPM	96	96	96	72	72	72
8	Shaft Dia in mm	35	35	38	49	49	49

Robust Build and Versatile Material Options

Perfect Bucket Elevators are engineered using high-strength polymer or steel buckets, complemented by mild or stainless steel frames. This construction ensures exceptional durability and corrosion resistance, making them suitable for demanding industrial environments in India. The powder-coated or painted surface treatment further prolongs service life, even when used outdoors or with abrasive materials.

Low Maintenance and Simple Service Access

Designed for minimal upkeep, these elevators feature centralized or manual lubrication systems and easy-to-access inspection panels. Operators can service and inspect machines efficiently, reducing downtime and enhancing reliability. The dustproof enclosure further limits maintenance frequency by protecting internal components from contamination.

Flexible Applications and Adaptable Design

With customizable discharge heights (up to 30 meters) and variable weight capacities (up to 1,000 kg), Perfect Bucket Elevators are tailored to specific process requirements. Their high efficiency and low noise/vibration levels make them suitable for ready-mix, feed, cement, grain transfer, and more, whether installed inside or outside.

FAQ's of Perfect Bucket Elevators:

Q: How are Perfect Bucket Elevators maintained, and what makes them low maintenance?

A: Perfect Bucket Elevators require minimal maintenance due to their centralized or manual lubrication systems and robust, dustproof enclosures. Inspection panels allow for quick access to internal components, streamlining routine service and minimizing operational interruptions.

Q: What materials are used for the buckets, and how do I choose between polymer and steel?

A: Buckets are made from either high-strength polymer or steel. Polymer buckets are lightweight and corrosion-resistant, ideal for less abrasive materials, while steel buckets offer greater strength and durability for handling heavier, abrasive loads. The optimal choice depends on the application and material type.

Q: Where can these elevators be installed and what environments are suitable?

A: These elevators are designed for both indoor and outdoor installations. Thanks to their corrosion-resistant construction and dustproof design, they perform reliably in harsh environments such as cement plants, feed mills, and grain storage facilities across varying climate conditions.

Q: What safety features are incorporated in Perfect Bucket Elevators?

A: Safety is a priority, with features including overload protection, emergency stop mechanisms, safety guards, and secure enclosures. These measures reduce risks during operation and meet stringent industrial safety standards.

Q: How customizable are the elevator's dimensions and discharge heights?

A: Perfect Bucket Elevators offer fully customizable discharge heights-up to 30 meters-and can be manufactured in dimensions tailored to specific project needs. This flexibility ensures seamless integration with existing process lines.

Q: What is the process for loading and unloading materials using these elevators?

A: Materials are loaded through an integrated intake hopper, which can include a vibration feature for optimal flow. The elevator then conveys bulk material upward with minimal spillage, discharging it at a specified height, controlled via electrical or remote start/stop mechanisms.
