Paddy Separator Double Body-PSD

Get a Price/Quote

MOQ : 1 Piece

Paddy Separator Double Body-PSD Specification

Features
Double Body Design, Compact Structure, Easy Maintenance

Noise Level
Low

Frame Type
Heavy Duty Mild Steel

Cooling System
Air Cooled

Accuracy
High Separation Accuracy

Frequency
50 Hz

Production Capacity
Up to 5 TPH

Voltage
415 V

Drive
Belt Drive

Model No
PSD

Machine Type
Double Body Paddy Separator

Motor Power
2 HP Each Body

Connectivity Options
Panel Based

Power Rating
2.2 kW

Lubricating System
Automatic / Centralized

Operating Temperature
-10C to 50C

Product Type
Paddy Separator Double Body

Technology
Modern Mechanical

Power Source
Electric

Operating Type
Automatic

Power
2-3 HP

Pressure
Atmospheric

Surface Treatment
Powder Coated

Dimension (L*W*H)
2200 x 1250 x 2100 mm

Weight (kg)
1500 kg

Color
White / Custom

Usage & Applications
Separation of Paddy from Brown Rice

Service Support
On-Site & Remote

Installation Type
Free Standing

Adjustability
Feed, Incline, and Louver Controlled

After-Sales Service
Available

Operating Personnel
Single Operator

Material Compatibility
All Varieties of Paddy

Tray Assembly
Stainless Steel

Spare Parts Availability
On Request

Paddy Separator Double Body-PSD Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
10 Pieces Per Month

Delivery Time
7-10 Days

About Paddy Separator Double Body-PSD

Double-body paddy separators are designed for medium to high-capacity rice mills of 5 to 12 TPH. These machines come with an automatic control Panel with VFD and SS Trays, as standard.

Salient Features

SS Tray for long life and perfect separation
VFD for speed adjustment to suit different paddy varieties. sensor-controlled panel board for auto on/off.
Easily adjustable tray inclination.

Specification

Model No.	Capacity of Rice, TPH	Power, HP x RPM	Weight in Kgs (App.)	Overall Dimensions in mm (L x W x H)
PSD 1 (46 x 20 x 2)	8-10	5 x 960	1240	1970 x 1760 x 2120
PSD 2 (60 x 20 x 2)	10-12	5 x 960	1380	2280 x 1860 x 2180
PSD 3 (46 x 16 x 2)	5-7	5 x 960	1140	1970 x 1760 x 1950

Enhanced Separation Efficiency

The Double Body-PSD leverages modern mechanical technology and precision adjustments to separate all paddy varieties from brown rice with exceptionally high accuracy. Its dual-section structure maximizes processing speed while maintaining quality results.

User-Friendly Operation

Designed for single-operator use, the automatic operation with panel-based connectivity and clear controls simplifies workflow. Feed, incline, and louver adjustments can be managed easily, allowing tailored processing for different paddy types.

Durable and Low-Maintenance Build

A heavy-duty mild steel frame, stainless steel tray assembly, powder coated surface, and centralized lubricating system ensure sturdy operation and reduced maintenance requirements, supporting consistent reliability in demanding environments.

Comprehensive Service Support

After-sales service is available through both on-site and remote channels. Spare parts can be requested as needed, and the support team offers guidance for installation, operation, and troubleshooting, ensuring seamless integration into your facility.

FAQ's of Paddy Separator Double Body-PSD:

Q: How does the Paddy Separator Double Body-PSD achieve high separation accuracy?

A: The machine utilizes a double body design with controlled feed, incline, and louver settings. These adjustments, combined with modern mechanical technology, ensure precise separation of paddy from brown rice, delivering consistently accurate outcomes.

Q: What varieties of paddy can be processed with this separator?

A: This separator is compatible with all varieties of paddy, thanks to its versatile adjustment controls and robust tray assembly. Whether processing short-grain or long-grain paddy, the machine adapts for optimal separation.

Q: When and where is after-sales service available for this machine?

A: After-sales service is available at your location (on-site) or remotely, as per your requirements. The manufacturer, supplier, and service provider network operable across India ensures timely assistance and support.

Q: What is the process for requesting spare parts for the Double Body-PSD?

A: Spare parts are available on request. You can contact the manufacturer or authorized supplier, specifying your machine's model number (PSD) and required components, to expedite procurement and minimize downtime.

Q: How easy is installation and operation for the Paddy Separator Double Body-PSD?

A: Installation is hassle-free, as the machine is free-standing and designed for quick setup. Operation requires just a single operator, using panel controls to manage key parameters and monitor performance efficiently.

Q: What are the main benefits of using this separator in rice milling operations?

A: The key benefits include high production capacity (up to 5 TPH), compact and sturdy construction, automated, low-noise operation, and reduced maintenance needs. It improves workflow efficiency and ensures consistently high-quality separation.
